2013 Data Collection
SABER became operational on January 8, 2002, and remained in Data Collection (DC) mode during 2013 except for the periods noted below.
- May 17 - TIMED demoted to SAFE
- 16 May 13:57 - TIMED demoted to SAFE.
- 16 May 22:54 - SABER returns to DC.
2013 Operational Changes
- No operational changes were made to SABER during 2013
2013 Trends
- Housekeeping - plotted parameters directly related to health and monitoring
- Responsivity - responsivity levels plotted for channels 1-10
- Scan Mirror - plot of scan mirror behavior for 2013
Coverage
2013 Commanding
2013 Limit Violations
Click here for a list of each command sent in 2013 along with a short description of that command's purpose.
Operational changes made to SABER in 2013 are noted below:
Trended parameters are divided into three sections:
The plot below shows the dates of TIMED Yaws, and the latitudes between which SABER observed during those Yaws
The small picture below shows the orientation of SABER on TIMED, and the latitudes observed in +X and -X travel
The breakdown of commands sent to SABER in 2013 is as follows:
| Command Type | Number of commands |
|---|---|
| Diagnostics or Testing | 0 |
| Memory Dump | 0 |
| Power-Up | 0 |
| Health and Maintenance | 1 |
| Operational Change | 0 |
| Total: | 1 |
For a list of each command sent in 2013 along with a short description of that command's purpose, click here.
During the year of 2013, there were no reported Red limit violations.
